| Frame | Double-layer U-shaped aluminum alloy / Galvanized iron (GI) |
| Thickness | 20mm / 21mm / 26mm / 47mm |
| Filter Material | Nanofiber |
| Connection Angles | Sturdy ABS plastic corner / Aluminum alloy corner / None |
| Reinforcement Support | Galvanized steel strip |
| Maximum temperature | 60°C (140°F) |
| Dimensions W x H x D | Pocket Quantity (pcs) | Rated Airflow | Rated Initial Pressure Drop (Pa) | |||||||||||
| M5 | M6 | F7 | F8 | F9 | ||||||||||
| (Inch) | (mm) | (m³/h) | (CMH) | (Pa) | (in. w.g.) | (Pa) | (in. w.g.) | (Pa) | (in. w.g.) | (Pa) | (in. w.g.) | (Pa) | (in. w.g.) | |
| 12 x 24 x 2 | 289 x 594 x 46 | 8 | 3,400 | 2001 | 55 | 0.22 | 58 | 0.23 | 75 | 0.3 | 110 | 0.44 | 120 | 0.48 |
| 20 x 24 x 2 | 492 x 594 x 46 | 6 | 2,850 | 1678 | 55 | 0.22 | 58 | 0.23 | 75 | 0.3 | 110 | 0.44 | 120 | 0.48 |
| 24 x 24 x 2 | 594 x 594 x 46 | 5 | 2,300 | 1354 | 55 | 0.22 | 58 | 0.23 | 75 | 0.3 | 110 | 0.44 | 120 | 0.48 |
| 12 x 24 x 2 | 289 x 594 x 46 | 4 | 1,700 | 1001 | 55 | 0.22 | 58 | 0.23 | 75 | 0.3 | 110 | 0.44 | 120 | 0.48 |
| 20 x 24 x 2 | 492 x 594 x 46 | 8 | 3,400 | 2001 | 70 | 0.28 | 75 | 0.3 | 110 | 0.44 | 150 | 0.6 | 170 | 0.68 |
| 24 x 24 x 2 | 594 x 594 x 46 | 6 | 2,850 | 1678 | 70 | 0.28 | 75 | 0.3 | 110 | 0.44 | 150 | 0.6 | 170 | 0.68 |
| 12 x 24 x 2 | 289 x 594 x 46 | 5 | 2,300 | 1354 | 70 | 0.28 | 75 | 0.3 | 110 | 0.44 | 150 | 0.6 | 170 | 0.68 |
| 20 x 24 x 2 | 492 x 594 x 46 | 4 | 1,700 | 1001 | 70 | 0.28 | 75 | 0.3 | 110 | 0.44 | 150 | 0.6 | 170 | 0.68 |
Remark:
1. Initial resistance performance tolerance is ±10%
2. Special dimensions available upon request
