| Model | Dimensions W x H x D | Air Flow | Initial Pressure Drop | Material | Media area | Gasket Thickness | Face-Guard | Targeted Gaseous | |||||
| (mm) | (ft) | (CMH) | (CFM) | (Pa) | (in.w.g.) | (m²) | (ft²) | (mm) | (in) | ||||
| PC-A2 | 594x594x292 | 24 × 24 × 12 | 3,400 | 2,001 | <120@2.5m/s | <0.48 @ 492 FPM | Galvanized steel/ Aluminum | 11.2 | 120.6 | 5 | 0.20 | Aluminum (Anode material), Galvanized iron | Acid airborne molecule (F,CI,NOx,SOx,H₂S) |
| PC-B2 | 594x594x292 | 24 × 24 × 12 | 3,400 | 2,001 | <120@2.5m/s | <0.48 @ 492 FPM | Galvanized steel/ Aluminum | 11.2 | 120.6 | 5 | 0.20 | Aluminum (Anode material), Galvanized iron | Alkaline airborne molecule (NH₃) |
| PC-C1 | 594x594x292 | 24 × 24 × 12 | 3,400 | 2,001 | <120@2.5m/s | <0.48 @ 492 FPM | Galvanized steel/ Aluminum | 11.2 | 120.6 | 5 | 0.20 | Aluminum (Anode material), Galvanized iron | Condensible Gases (VOC) |
| PC-D2 | 594x594x292 | 24 × 24 × 12 | 3,400 | 2,001 | <120@2.5m/s | <0.48 @ 492 FPM | Galvanized steel/ Aluminum | 11.2 | 120.6 | 5 | 0.20 | Aluminum (Anode material), Galvanized iron | Dopant (Boron, Phosphorus) |
